Product Description

TECHNICAL SPECIFICATIONS:

• STAND: Single mold sturdy stand with anti rust materials. Extended base for better stability.
• OBSERVATION HEAD: Siedentopf Trinocular 30o inclined, 360 o rotatable. Interpupillary distance adjustable between 55-75mm. Diopter adjustment  ring on ocular tube (+5).Vetical Phototube for micro photography.
• EYEPIECE: WF Eyepiece 10x (PAIRED) FOV 18mm.
• NOSEPIECE: Reverse angle quadruple nosepiece revolves on ball bearing with positive indexing. Soft rubber knurled grip on nosepiece.

OBJECTIVES (Infinity Plan Objectives)

• Infinity Plan achromatic 4x

• Infinity Plan achromatic 10x

• Infinity Plan achromatic 40x (SL)

• Infinity Plan achromatic 100x (SL) oil

STAGE: Mechanical stage Size 140mmx132mm, supported on ball bearing guide ways and having low positioned co-axial controls for stage movement. Cross movement 76mmX 50mm. FOCUSING

Co-axial focusing control with ball bearing guide ways & large knobs, pre focusing lever & tension adjustment ring. The slow motion has  1DIV=0.002mm.

CONDENSER:Sub stage abbe condenser NA 1. 25 having a spherical lens, adjustable iris diaphragm and swing out filter holder.

ILLUMINATION The built-in-base illumination system with ultra high brightness single 3W LED cold light source. Brightness control knob.

STANDARD ACCESSORIES

• Dust cover
• Operating Manual
• Guarantee card
• Styrofoam molded pack

PACKAGING CONTENTS

• Blue filter.
• STYRO FOAM Molded pack.

WARRANTY INFORMATION

• 2 Years parts.
• 1 year Electronics
