Product Description

Weswox  Fully Automatic Microtome Latest Model

SPECIAL FEATURES :

Rust proof construction.

Lockable hand wheel at any position allowing change of blade/specimen easier and safe.

Lateral knife adjustment to ensure that the entire width of the blade is used without releasing the blade clamping mechanism.

Large storage capacity on the top of the instrument for easy access of tools.

Finger protection guard to protect the used from any injuries caused due to blade.

Robust and stable base plate for maximum stability to the microtome.

Ergonomic and user friendly design.

Section Waste tray to collect section waste and is easily removable for cleaning purposes.

LCD Display with Feather Touch Keypad

Slicing/Trimming Mode

TOUCH Fast Forward/Backward Function

TOUCH Increase/Decrease Section Thickness

TOUCH Section Counter/Section thickness display

Motorized Feed & Coarse Drive in two speeds.

Sectioning Mode: Semi-automatic, Fully automatic.

precision micrometer feeding system with 3-4 nodes of sectioning

adjustable specimen retraction system

electromechanical feed system for fine and trimming section thickness and forward and backward specimen movements via stepping motor.

able to provide section thickness range of 0.5 micron to 100 micron.

trimming thickness feed via precision stepping motor for 5 micron to 100 micron.

knife holder to hold both high profile & low profile disposable blades with UCC & SSC clamps.

Horizontal feed range 24-28mm and vertical specimen stroke length 65+/-mm

Operable at 230V, 50Hz

TECHNICAL SPECIFICATIONS:

Section thickness setting: 0.5-60m

Setting values : from 0.5m-2m in 0.5m increments

                           From 2m- 20m in 1m increments

                           From 20m-60m in 5m increments

Trimming Thickness Setting: 1m-100m

Setting values : from 1m-20m in 1m increments

                           From 20m- 60m in 5m increments

                           From 60m- 100m in 10m increments

Minimum Setting value: 0.5m

Object feed: 30mm

Max. Specimen Size: 50X50mm

Sectioning speed range: Adjustable

Operation: Semi-automatic, Fully automatic.

Nominal Voltage: 220V, 50Hz/110V, 60Hz

Other features are mentioned in our catalogue
