Product Description

SPECIFICATIONS:

• Wavelength Range: 325-1000nm.
• Light Source Lamp: Tungsten Halogen Lamp 20W/12V.
• Wavelength Accuracy: +2 nm
• Wavelength Repeatability: 1 nm
• Band Width: 2nm
• Photometric Accuracy: +0.5%(T)
• Photometric Reproducibility:  0.2%(T)
• Stray Light: +0.2%(T)
• Noise: +0.2%(T)
• Size: (LxWxH) Main unit: 370x320x190mm  Carton: 450x420x280mm.
• Weight: N.W-7kg G.W-9.5kg.
• Power Requirement: 220V/110V+50/60 Hz
• Interface: RS232 serial & parallel interface.

STANDARD CONFIGURATION

• Main Instrument1 unit
• Optional Manual  1no.
• Power Cable  1no.
• Glass Cell 10mm 4 no.
• Software CD  1 no.
• RS232 Cable  1 no.
• Dust Cover  1 no.
