SENIOR PROJECTION MICROSCOPE SENIOR PROJECTION MICROSCOPE
SENIOR PROJECTION MICROSCOPE
SENIOR PROJECTION MICROSCOPE

SENIOR PROJECTION MICROSCOPE

Product Details:

X

Product Description

OBSERVATION SCREEN

Having 195mm dia graduated screen rotatable through 360o with pointer built in compensating eyepiece to provide magnification range from 100x to 1500x.

NOSEPIECE

Triple/Quadruple nosepiece revolves on ball bearing with rubber grip and positive click stop.

EYEPIECE

HKW 10x eyepieces (paired).

OBJECTIVES

KEOWA Achromatic objectives 4x, 10x, 20x, 40x, or 60x (SL) (Any 4 Nos.)

STAGE

Coaxial built-in Mechanical stage for comfortable & convenient manipulation of specimen slides.

FOCUSING

Focusing is done by vertical movement of stage, coarse adjustment by rack & pinion and fine movement by screw lever mechanism, driven by graduated knob.

CONDENSER

Bright fields, knob condenser NA 1.25 with iris Diaphragm and swing out filter holder is provided, which can be operated through a rack pinion knob.

ILLUMINATION

Equipped with Super Bright Halogen Lamp 12V-100W and built-in-solid state light control arrangement

MAGNIFICATION

Total magnification from 125x till 1000x.

PACKAGING CONTENTS

The concomitant Accessories - a spare bulb, fuse, vinyl cover & power cord are housed in a drawer on the side wall of the microscope.Complete in a cardboard box.

WARRANTY INFORMATION

2 Years parts.



THE WESTREN ELECTRIC AND SCIENTIFIC

* Tips on getting accurate quotes. Please include product name, order quantity, usage, special requests if any in your inquiry.
