Product Description

DISCRIPTION:

Nano-WSPECTRO-31002 is conventional laboratory equipment not only widely used in molecular biological experiments, such as DNA, RNA, and protein detection but also used in absorbance detection for the general substance analysis. It includes three common detection to the nucleic, acid, nucleic acid maker and proteins.

The variable pathlength of NanoReady realizes both the minimum sample volume detection as low i0.5 l suitable for precious sample, and the detection lo the high concentration sample without dilution at all including the liquid drop, it builds in the standard cuvette detection module for more use.

FEATURE:

• High Sensitivity: 2028 linear CCD detection unit, new generation product, has higher sensitivity, accuracy as well as repeatability.
• Stability for the long life: Long-life xenon flash lamp of Hamamatsu ensures stability of detection and the long life of instruments. The lifting detection base with sliding bearing structure  high precision, not easy to damage.
• Variable Pathlength: The mini detection path length is 0.05mm; samples with high concentration can be detected directly without dilution.
• The max -15000ng/ l dsDNA, the smallest detection volume of precision samples is 0.5l. The user-defined setting are allowed if the pathlength is more than 1mm. The instrument has flexible and convenient detection function.
• Ultra wide wavelength range: With continuous wavelength range as 185-910nm, the instrument can detect various sample through selecting any band. It adapts to a variety or detection requirements with wide range of near infrared wavelength.
• Accurate Path length: The Stepper motor combined unique double unique double track technology (DPTL). Allows the precision of optical pathlength as 0.001mm thus to achieve highly repeatability of absorbance detection.
• Cuvette detection mode: The cuvette detection mode come with magnetic stirrer function. User can set the heating functioned stirring speed for dynamic analysis detection. And the user can define different pathlength, such as 1mm, 2mm, 5mm, 10mm, (for Model: FC-1100 only).
• Unique Designed Pipette holder for easy sample adding: Auxiliary holder for adding liquid can ensure the accuracy of adding liquid during micro measurement. It is also suitable for other mainstream brand of micro UV-VIS Spectrophoto meter in the market to achieve a stable and simple process of adding liquid.
• User- friendly software: The simple designed interface makes the software user friendly. It will save the detection data and name file automatically and it is review this files. There is no need to worry about the loss of experimental data. Set U disk upgrade interface and maintain the latest and most complete function at any time.
• Wireless Connection: Wifi connected PAD to control the detection and result and storage without need the cables. Dynamic detection realizes remote controlling and timing reading the result without manual intervention.

SPECIFICATIONS:

• Detector- 2048-element liner CCD array
• Mini Sample Amount (l)0.5
• Mini. Path length (mm)0.05
• Wavelength Range (nm)185-910
• Wavelength Accuracy (nm)+1
• Spectral Resolution (nm)<1.8(FWHMat Hg 253.7nm)
• Absorbance Accuracy-0.002n(1mm optical length)
• Absorption Accuracy-3%(at 0.64A at 350nm)
• Limit of Detection - 2ng/l dsDNA
• Max Detection Concentration15000ng/l dsDNA
• Detection time <5 Sec.
• Cuvette Mode - Heating Temp.(C) 37+0.5 Null
• Mixing Speed (RPM)150-850 - Null
• Optical Length (mm)10,5.2,1- Null
• Limit of Detection - 0.4ng/-l dsDNA Null
• Max. Detection750ng-l ds DNA Null
• Data Interface - USB
• Wireless Connection Wifi
• Software Update USB direct update
• Accessory - Pipette holder
• Power- AC110V-220V 50Hz/60Hz (Power Adapter)
• Net Weight - 2.1kg2.0kg

FUNCTIONS:

• Nucleic acid detection: Built-in common calculation formula of dsDNA,ssDNA,RNA, can get concentration and punty of sample automatically.
• UV visible custom scanning: In the wavelength range, set the detected wavelength through increasing or decreasing wavelength with 1nm as expected.
• Protein detection: Can detect the concentration of protein solution, or detect protein concentration of dye marker. Built-in common detection method of BCA, Bradford, Lowery, Pierce 660nm.
• Nucleic acid fluorescence marker detection: Preinstall extinction factor of commonly used fluorescent dyes of dsDNA,ssDNA,RNA, Oligo-DNA,Oligo- RNA.
• Cell detection: Can detect absorbance value at 600nm automatically. Meanwhile, it can detect absorbance value at any band under set wavelength range.
