Microprocessor UV-VIS Double Beam Spectrophotomter Exclusive Model Microprocessor UV-VIS Double Beam Spectrophotomter Exclusive Model
Microprocessor UV-VIS Double Beam Spectrophotomter Exclusive Model
Microprocessor UV-VIS Double Beam Spectrophotomter Exclusive Model

Microprocessor UV-VIS Double Beam Spectrophotomter Exclusive Model

Product Details:

X

Product Description

DISCRIPTION:  WSPECTRO-12001EX spectrophotometer are advance double beam optical system. Double beam optical stricter can inhibit the drift, Suitable for long time test.  WSPECTRO-12001EX with 0.5/1/1.5/2/4/5nm Variable bandwidth. They are suitable of research, biochemical and pharmaceutical lab application.

FEATURES:

  • Double beam ensure low drift, low noise and low stray light.
  • High speed MCU, high precision AD, large storage capacity.
  • Large LCD display (320x240 Dots).
  • 1.0nm or variable Bandwidth meets Pharmacopoeia.
  • Data and Curve can be
  • Online software upgrade capability.
  • Lamps can be turned on/off individually.
  • Easy to change Pri-aligned lamps.

SPECIFICATIONS:

  • Wavelength Range -  190-1100nm
  • Spectral Band width- 0.5/1/1.5/2/4/5nm Variable
  • Optical System Double beam, Blazed Holographic Grating (1200 lines/mm)
  • Wavelength Accuracy+0.5nm
  • Wavelength Repeatability <0.2nm
  • Wavelength Setting  Auto, Resolution 0.1nm
  • Photometric Range0-200% T, -4-4A, 0-9999C
  • Photometric Accuracy+0.002 A (0-0.5A), +0.003A(0.5-1A), +0.3%T (0-100%T)
  • Photometric Repeatability<0.001 A (0-0.5A), <0.002A (0.5-1A), <0.2%T (0-100%T)
  • Stray Light <0.05%T (220/360nm)
  • Scan Speed High, Medium, Low, Max.2000nm/minute
  • Baseline Flatness+0.001A
  • Stability +0.001A/h (500nm,0A)
  • Noise <0.2%T/3min (250/500nm,0%T);<0.3%T/3min (250/500nm,100%T)
  • Sample Compartment10mm Path length Cuvette
  • Detector-Silicon Photodiode
  • Lamp-Tungsten Lamp & Deuterium Lamp (Pre-aligned)
  • Display-Graphic LCD (320x240 Dots)
  • Keypad 30-key Alphanumeric Membrance Keypad
  • Output Port-USB port
  • Printer -Mini Serial Printer; PC Printer
  • PC Software-PC Scanning Software
  • Power Requirements-AC 90-250V, 50/60Hz
  • Dimension-635x515x255mm
  • Weight -26kg

FUNCTIONS

  • Photometric
  • Quantitative (Standard Curve)
  • WL Scan (Spectrum Scan)
  • Time Scan (Kinetics)
  • DNA/Protein Test
  • Multi-WL Test
  • System Utility

STANDARD ACCESSORIES

  • Glass Cell  -4 no.
  • Quartz Cell-2 pcs.
  • Instrument Cover-1 no.
  • Software CD-1 no.
  • USB Cable-1 no.
  • Operational Manual-1 no.
  • Software Manual-1 no.
  • Software Key-1 no.
