Double Beam Spectrophotomter Xenon Lamp Double Beam Spectrophotomter Xenon Lamp
Double Beam Spectrophotomter Xenon Lamp
Double Beam Spectrophotomter Xenon Lamp

Double Beam Spectrophotomter Xenon Lamp

Product Details:

X

Product Description

FEATURE:

High quality flashing xenon lamp which can start to test directly without preheating,

Powerful functions like Photometric measurement, Quantitative measurement, Kinetics, Spectrum Scan, DNA/Protein test, Multi-wavelength test, etc.

In-house massive memory is capable of saving up to 1024M for test data & working curves.

Supports USB storage, The USB port can be used for data transfer, which is easily exported to Excel for further processing, analysis and storage

Large sample chamber can accommodate 5-100mm cuvettes of all kinds. Provide at Extra cost.

Extensive accessories are optional, such as auto 8-cell holder, peltier/sipper system, 21 CRR compliant software Provide at Extra cost etc.

Auto Wavelength Setting

Tungsten/Deuterium Lamp can be Turned ON/OFF Individually to Extend Lifetime

On-Screen Standard Kinetic Carve Display

SPECIFICATIONS:

Optical SystemDouble Beam, Grating 1200 lines/mm

Wavelength Range        190 nm-1100nm

Spectral Bandwidth        1 nm

Wavelength Accuracy±0.1nm@656.1nm, ±0.3nm@all

Wavelength Repeatability≤0.1nm

Photometric Accuracy0.2%T(0~100%T),±0.002A(0-0.5A),±0.004A(0.5-1A)

Photometric Repeatability≤0.15%T(0-100%T), 0.001A(0-0.5A), 0.002A(0.5-1A)

Photometric Range        0-200%T, 0.3~3A, 0-9999C (0-9999F)

Stray Light        ≤0.03%T@220nm, 360 nm

Stability                ±0.0005A/h@500nm

Baseline Flatness        ±0.001A

Noise        0.0005A@500nm

Work Mode        T%Abs, Conc., Reflectance, E,

Scanning SpeedHi, Med, Low (Max. 3000nm/min)

Wavelength Setting        Auto

Display        7” TFT Color Screen

Light Source        Imported Xenon Lamp

Detector                Imported Silicon Photodiode

Cuvette Holder10mm single hole cell holder

Output        USB drive, USB host, RS232

Power        AC 220V/50Hz or AC 110V/60Hz

Shipping Size        810*660*390mm

Gross Weight        27kg

Standard Accessories        10mm glass cuvette x 4, 10mm quartz cuvette x2, Power cord, User’s Manual, PC software
