Product Description

TECHNICAL SPECIFICATIONS:-

OPTICAL SYSTEM: Universal Infinity corrected Optical system

STAND: Stable & sturdy C shaped stand with well-contoured modular base, corrosion resistant paint and heat resistant pads. Extended base for better stability.

VIEWING HEAD: Siedentopf Binocular/Trinocular tube, inclined at 30 rotatable through 360 with IPD 55-75 mm. Anti fungus treated.

EYEPIECES: Focussable Eyepiece WF 10x FN 22 paired with eye guards, anti-fungus treated.

NOSEPIECE: Low friction & fully parafocal Reverse angle quadruple Revolving nosepiece (Ball bearing type) with click stop & rubber grip.

OBJECTIVES: KEOWA BJ series All New High Definition Infinity Plan DIN parafocal Plan Achromatic lenses, Anti fungus treated  objetives:

PLAN ACHROMAT 4x/0.10

PLAN ACHROMAT 10x/0.25

PLAN ACHROMAT 40x(SL)/0.65

PLAN ACHROMAT 100x(SL, Oil)/1.25.

FOCUSING: Ergonomic low position co-axial coarse and fine focusing system on ball bearing guideways.  Tension MODULE adjustment ring provided. Fine Graduation 2-3 micron.

STAGE: Ceramic coated rackless Double layer graduated mechanical rectangular stage  size 140 x 132mm wire cross travel 75 (X) x 50 (Y) mm on ball bearing co-axial controls spring clip specimen holder.

CONDENSER: Movable ABBE condenser, with aspheric lens NA 1.25, daylight blue filter & Iris diaphragm. Centrable

ILLUMINATION: Koehler Illumination, Super Bright White LED cold Light, Optional 6V 20W Halogen Lamp

POWER: Universal Power Supply 100 V to 240 V,AC 50-60 Hertz, CE Compliant.

PACKAGING CONTENTS

The microscope is packed inside a STYROFOAM box with Dust Cover.

STANDARD ACCESSORIES

Styrofoam molded box, dust cover, instruction manual, and fuse.

OPTIONAL ACCESSORIES:

Upgradeable to Fluorescence attachment with battery backup.
