Product Description

DISCRIPTION:

• The Nano WSPECTRO-32001 is an advanced model of Micro UV VIS Spectrophotometer
• based on with full range of wavelength (200-800nm). It is with an
• added new function of bacterium cell concentration measurement (OD600) in
• a cuvette. The Nano WSPECTRO-32001 only requires 0.5-2ul sample to measure nucleic acids,
• protein as quickly like do. Nano WSPECTRO-32001 come with a 7 inch touch screen
• and integrated Android operating system, with no computer required.It is an ideal
• equipment for a biology laboratory to make life science research more efficient

FEATURE:

•  7 inch touch screen with simple interface. No computer required
•  Android operating system with free software update
•  Only require 0.5-2ul sample to perform accurate measurements.
•  Long lifes Xenon flash lamp for up to 10 years
•  Flexible data output. The data can be printed with built-in printer, and output via USB memory stick
•  OD600 measurement, ideal for bacterial concentration measurement
•  Direct micro-volume measurement with 0.5-2ul of sample. Eliminates the need for expensive accessories.
•  Wide range of wavelength (200-800nm)
•  Turn on and instantly measure without lamp warm up time; Full scan capability from 200-800nm with 6   sec.
•  Switch off automatically when the machine is idle for more than 5mins, and awake by touching the screen.

SPECIFICATIONS:

• Wavelength Range200~800nm
• Sample Size0.5~2.0ul
• Path Length0.2mm (For high concentration measurement)
•  1.0mm (Ordinary concentration)
• Light Source Xenon flash lamp
• Detector Type3864-element linear silicon CCD array
• Wavelength Accuracy1nm
• Spectral Resolution3nm (FWHM at Hg 546nm)
• Absorbance Precision0.003Abs
• Absorbance Accuracy1% (7.332Abs at 260nm)
• Absorbance Range0.02 - 100A
• Detection Range10~5000ng/ul (dsDNA)
• Measurement Time<6s
• Dimensions (W x D x H)mm210 x 268 x 181
• Data Output USB, SD-RAM Card
• Weight     2.8kg
• Sample Pedestal Material Aluminum alloy and Quartz fiber
• Operating Voltage24VDC
• Operating Power Consumption40W
• Standby Power Consumption5W
• Software Compatibility OD600nm Measurement:Android System
• Light SourceLED
• Wavelength Range600;±8nm
• Abosorbance Range0~4A

ACCESSORIES:

• Cuvette 10mm 2 pcs
• Adapter
