Product Details:

X

Product Description

DISCRIPTION:

  • The Nano WSPECTRO-32001 is an advanced model of Micro UV VIS Spectrophotometer
  • based on with full range of wavelength (200-800nm). It is with an
  • added new function of bacterium cell concentration measurement (OD600) in
  • a cuvette. The Nano WSPECTRO-32001 only requires 0.5-2ul sample to measure nucleic acids,
  • protein as quickly like do. Nano WSPECTRO-32001 come with a 7 inch touch screen
  • and integrated Android operating system, with no computer required.It is an ideal
  • equipment for a biology laboratory to make life science research more efficient



FEATURE:

  •  7 inch touch screen with simple interface. No computer required
  •  Android operating system with free software update
  •  Only require 0.5-2ul sample to perform accurate measurements.
  •  Long lifes Xenon flash lamp for up to 10 years
  •  Flexible data output. The data can be printed with built-in printer, and output via USB memory stick
  •  OD600 measurement, ideal for bacterial concentration measurement
  •  Direct micro-volume measurement with 0.5-2ul of sample. Eliminates the need for expensive accessories.
  •  Wide range of wavelength (200-800nm)
  •  Turn on and instantly measure without lamp warm up time; Full scan capability from 200-800nm with 6   sec.
  •  Switch off automatically when the machine is idle for more than 5mins, and awake by touching the screen.



SPECIFICATIONS:

  • Wavelength Range200~800nm
  • Sample Size0.5~2.0ul
  • Path Length0.2mm (For high concentration measurement)
  •  1.0mm (Ordinary concentration)
  • Light SourceXenon flash lamp
  • Detector Type3864-element linear silicon CCD array
  • Wavelength Accuracy1nm
  • Spectral Resolution3nm (FWHM at Hg 546nm)
  • Absorbance Precision0.003Abs
  • Absorbance Accuracy1% (7.332Abs at 260nm)
  • Absorbance Range0.02 - 100A
  • Detection Range10~5000ng/ul (dsDNA)
  • Measurement Time<6s
  • Dimensions (W x D x H)mm210 x 268 x 181
  • Data OutputUSB, SD-RAM Card
  • Weight     2.8kg
  • Sample Pedestal MaterialAluminum alloy and Quartz fiber
  • Operating Voltage24VDC
  • Operating Power Consumption40W
  • Standby Power Consumption5W
  • Software Compatibility OD600nm Measurement:Android System
  • Light SourceLED
  • Wavelength Range600±8nm
  • Abosorbance Range0~4A



ACCESSORIES:

Cuvette 10mm 2 pcs

Adapter
